Cooling · Reference M1850TD6
Cooling Tunnel
Cooling Tunnel · M1850TD6 · Cooling
Controlled cooling,
Controlled cooling,
perfect shine.
A high-capacity cooling tunnel for enrobed products — constant temperature for a stable process and a flawless shine on every piece. Compact, energy-efficient and built to the hygiene standards of a professional line.
Set temperature
5–20 °C · air / convection cooling
Belt speed
0.3–1.8 m/min (continuously adjustable)
Belt width
300 mm effective (325 mm total), food-grade
Dimensions
7.75 × 0.55 × 1.57 m (1.25 m closed) · 580 kg
Public price
€44,900 · exworks, excl. VAT
Power
3 kW · 220–230 V single-phase · R134A
Key features
Built for enrobed production.
Optimised for large-scale production of enrobed products
Centralised cooling group with channelled cold-air flow
Continuously adjustable belt speed (≈ 3.5–20 min over 6 m)
Food-grade conveyor belt and stainless-steel covers
Pairs with the M1850 enrobing grill and CW40 / CW60 / CW80 tempering machines
Bottom and partial enrobing options available on request
